One year warranty 5 liter juice pet bottle blowing machine

Group Automatic Extrusion Blow Molding Machines
Min. Order 1 piece
Terms of Payment all
Update Time 2020-08-31
Item specifics
ApplicationBottle
Plastic ProcessedPET
Voltage380V
Healing power24kw
  • Description
  • Product review
Quick details

Condition: New Application: Bottled Plastic Processing: PET

Brand Name: COSTAR Voltage: 380V Power (W): 24

Automatic: Yes Weight: 1850kg Certification: TUV

Warranty period: 1 year Number of cavity: 1 cavity Repair power : 24kw

Energy saving: Yes Color: Any customer who needs color Clamping force: 12000N

Clamping stroke: 125mm                                             host weight: 1850kg                                   theoretical output: 800-1000bph
Working pressure: 7-9kg/cm2 After-                                    sales service: Video technical support
Size (length * width * height): 1950 * 1850 * 2100 (mm) preform loader  size: 2180 * 740 * 1900mm

Place of Origin: Jiangsu Province, China (Mainland) Blow Molding Type: Injection Blow Molding

Product specification





CST -1000SG

Clamping force

kg

12000

Clamping stroke

Mm

125

Stretch stroke

Mm

300

Bottom stroke

Mm

40/70

Cavity spacing

Mm

\

Number of cavities

Cavity

1 piece

Transport unit

A

26

Theoretical output

bph

800-1000

Total power

Work

26

Healing power

Work

16 * 1.5KW = 24

Number of lights

Number of layers

8

Operating Pressure

kg/cm2

7-9

Low Pressure Air Consumption

liters / min

1600

Blowing Pressure

kg/cm2

20-30

High Pressure Air Consumption

liters / min

1600

Operating Pressure

kg/cm2

2-4

Temperature Range

°C

10-12

Consumption

kcal/hr

2000

Flow Rate

liters / min

130

Main Machine Dimensions

mm(L*W*H)

1950*1850*2100

Main Machine Weight

kg

1850

Preform Loader Dimensions

mm(L*W*H)

 \

Preform Loader Weight

kg

 \



Product Feature

1--Adopt special electronically controlled loop design while heating lamps; High efficiency in simultaneous controlling one lamp or large quantities, lower power consumption.

2--Adopt heat transfer and feedback theory to decide the shape and thickness of bottle embryo.

3--Heating furnace is always under stable temperature. The embryo will be heated evenly, not be influenced by outside environment.

4--Air circuit system consists of movement and blowing so as to meet the needs of different air pressure ,Also to provide stable high voltage for blowing different shapes of big bottles.
5--The system is equipped with silencer connecting rod and articulated refueling devices.

6--Two modes of operation, automatic mode and semi-automatic mode .

7--Auto. low investment, one person enough, easy to use and safe.

8--Cooling system with cold air circulating ensures same heat exposure of inner and outer of bottles.




Supply Ability

Supply Ability:400 Set/Sets per Month pet bottle blowing machine price

Packaging & Delivery

Packing details: 1 set of 1 year warranty, 5 liters of juice pet blow molding machine, the price is wooden pallet packaging, standard shipping packaging injection molding mold
Shanghai Port/Ningbo Port
delivery time
Quantity (set)1-1> 1
Eastern Time. Time (days)30To be discussed


Payment and shipping
